Self-cleaning, continuous flow
Automatic backflush or scraper cycles clear the mesh on differential pressure or timer — no stopping, no manual basket rinsing.
Screen Filter
Continuous screening that cleans itself — a self-cleaning screen filter that traps leaves, debris and coarse-to-medium solids on a stainless-steel mesh, then automatically backwashes or scrapes the screen clear so it keeps running without manual cleaning or stopping. Protects pumps, valves and downstream filtration with low pressure loss in fresh and salt water.
- ConnectionDN50–DN150 + intake type
- Capacity5–90 m³/h
- Mesh0.2–2 mm selectable
- ScreenSS304 / SS316
ISO 9001 CE OEM / ODM
15+ years in aquaculture engineering · Trusted by Japfa Group, Japan Nissui & Tropo Farms · Shipped worldwide in one container
Product Description
Through practice, the sieve bend is proved to have the advantages of zero energy, simple construction, and a remarkable filtration effect. The sieve bend is designed detachable, just plug in and pull out then can complete the installation of the sieve bend screen, super easy!
Advantage:
1) Consulting services are available and custom designs are welcomed!
2) We offer and provide a range of solutions for clients’ selection.
3) We offer practical solutions, premium quality products alongside competitive prices, low minimum orders, and prompt delivery.
4) All of our equipment guarantee one year and lifetime warranty.
5) Support onsite installation and send engineer for debugging
6) We are more than happy to answer even the small questions for you and we will gladly give you a bid on any item you are interested in.
Application
Specifications
Models & configuration
Model series integrated from industry practice — final specifications are confirmed by SIGMA's production line per project.
| Model | Capacity | Typical use | Core configuration |
|---|---|---|---|
| SIGMA-SCF-50 | 5–10 m³/h | ||
| SIGMA-SCF-80 | 15–25 m³/h | ||
| SIGMA-SCF-100 | 30–45 m³/h | ||
| SIGMA-SCF-150 | 50–90 m³/h | ||
| SIGMA-SCF-INTAKE | Sized per farm |
| Mesh range | Approx. 0.2–2 mm coarse debris screening; finer mesh available for sieving duty |
|---|---|
| Screen material | SS304 / SS316 (316L for saltwater) |
| Housing | PP / stainless steel / FRP |
| Self-cleaning | Differential-pressure or timer triggered automatic backflush or scraper — continuous operation, no shutdown |
| Water feed | Inline pressure feed or gravity intake |
| Water type | Freshwater / saltwater |
| Options | Duplex changeover, sight glass / pressure gauge, PLC-controlled backwash |
System composition
Protects pumps and downstream stages
Catches leaves, scales and stray debris before they reach pumps, valves, UV and biological filtration.
Low pressure loss
High open area keeps head loss minimal, with full flow restored after every clean.
Selectable mesh
Coarser screens for intake protection, finer mesh for sieving — matched to the duty.
316L corrosion resistance
Suited to seawater lines and intake structures.
Unattended, low maintenance
Runs 24/7 with few moving parts and few failure points.
Application
- Pump-protection and intake debris screening in RAS pipelines
- Coarse screening at sea- and freshwater intake sources
- Pre-filtration ahead of sand or drum filters
- Inlet/outlet protection for koi ponds and aquaria
FAQ
Frequently asked questions
How does a self-cleaning screen filter clean itself?
As solids build on the stainless-steel mesh the pressure differential rises (or on a set timer), triggering an automatic backwash / scraper cycle that flushes the debris to drain and restores full flow without opening the unit or interrupting the process.
What does a screen filter protect in a RAS?
It traps leaves, scales and coarse-to-medium suspended solids to protect pumps, valves and downstream filtration, and is used as an inline strainer, an intake screen on the water source, or a pre-filter ahead of sand or drum filtration.
Can the mesh size be changed?
Yes — the 316/304 stainless mesh is selectable to match the duty, coarser for intake protection and finer for sieving, with low pressure loss.
Does the screen filter run continuously?
With automatic cleaning it runs 24/7 unattended and low-maintenance, suited to both fresh- and sea-water.
